Description
| Product | Inlet End Connection | Outlet End Connection | Tube O.D. (in) | Tube O.D. (mm) | Orifice (mm) | Dimension L1 (mm) | Dimension L2 (mm) | |
| FTH-4T-S316 | 1/4″ Hy-Lok | 1/4″ Hy-Lok | 1/4 | 4.40 | 33.00 | 33.00 | ||
| FTH-6T-S316 | 3/8″ Hy-Lok | 3/8″ Hy-Lok | 3/8 | 4.40 | 36.20 | 36.20 | ||
| FTH-8T-S316 | 1/2″ Hy-Lok | 1/2″ Hy-Lok | 1/2 | 4.40 | 38.70 | 38.70 | ||
| FTH-8M-S316 | 8mm Hy-Lok | 8mm Hy-Lok | 8 | 4.40 | 38.70 | 38.70 | ||
| FTH-12M-S316 | 12mm Hy-Lok | 12mm Hy-Lok | 12 | 4.40 | 38.70 | 38.70 | ||
| FTH-16M-S316 | 16mm Hy-Lok | 16mm Hy-Lok | 16 | 4.40 | 38.70 | 38.70 |
