| Product | Orifice (in) | Orifice (mm) | Flow Coefficient (Cv) | End Connection | End Connection Size (in) | End Connection Size (mm) | Dimension E (mm) | Dimension H (mm) | Dimension C (mm) | Dimension F (mm) | Dimension G (mm) | Dimension J (mm) | |
| SO1BZCO-4-S316 | 0.188 | 4.80 | 1.2 | O-Ring Face Seal Fittings | 1/4 | 47.70 | 57.15 | 66.60 | 31.80 | 16.75 | 33.00 | ||
| SO2BZCO-8-S316 | 0.411 | 10.40 | 7.5 | O-Ring Face Seal Fittings | 1/2 | 64.80 | 111.00 | 82.80 | 44.20 | 22.25 | 44.50 | ||
| SO1BZCR-4-S316 | 0.188 | 4.80 | 1.2 | Metal Gasket Face Seal Fittings | 1/4 | 47.70 | 57.15 | 63.60 | 31.80 | 16.75 | 33.00 | ||
| SO2BZCR-8-S316 | 0.406 | 10.30 | 7.5 | Metal Gasket Face Seal Fittings | 1/2 | 64.80 | 111.00 | 92.00 | 44.20 | 22.25 | 44.50 |
