| Product | Tube O.D. (D) (in) | Tube O.D. (D) (mm) | Male Pipe Size P (Nom.) | Male Pipe Size P (mm) | d min. | Dimension L | Series | Material | Pipe Thread | Type | Quality System Certificates | |
| SAPW-4T-4P-STEL | 1/4 | 6.35 | 1/4 | 13.70 | 4.32 | 28.96 | SAPW | Carbon Steel | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-6T-8P-STEL | 3/8 | 9.52 | 1/2 | 21.30 | 6.86 | 37.08 | SAPW | Carbon Steel | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-8T-8P-STEL | 1/2 | 12.70 | 1/2 | 21.30 | 9.40 | 42.16 | SAPW | Carbon Steel | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-8T-12P-STEL | 1/2 | 12.70 | 3/4 | 26.67 | 9.40 | 42.67 | SAPW | Carbon Steel | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-12T-12P-BRAS | 3/4 | 19.50 | 3/4 | 26.67 | 14.73 | 47.50 | SAPW | Brass | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-4T-4P-BRAS | 1/4 | 6.35 | 1/4 | 13.70 | 4.32 | 28.96 | SAPW | Brass | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-6T-8P-BRAS | 3/8 | 9.52 | 1/2 | 21.30 | 6.86 | 37.08 | SAPW | Brass | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-8T-8P-BRAS | 1/2 | 12.70 | 1/2 | 21.30 | 9.40 | 42.16 | SAPW | Brass | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-8T-12P-BRAS | 1/2 | 12.70 | 3/4 | 26.67 | 9.40 | 42.67 | SAPW | Brass | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-12T-12P-BRAS | 3/4 | 19.50 | 3/4 | 26.67 | 14.73 | 47.50 | SAPW | Brass | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-4T-4P-S316 | 1/4 | 6.35 | 1/4 | 13.70 | 4.32 | 28.96 | SAPW | Stainless Steel 316 | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-6T-8P-S316 | 3/8 | 9.52 | 1/2 | 21.30 | 6.86 | 37.08 | SAPW | Stainless Steel 316 | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-8T-8P-S316 | 1/2 | 12.70 | 1/2 | 21.30 | 9.40 | 42.16 | SAPW | Stainless Steel 316 | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-8T-12P-S316 | 1/2 | 12.70 | 3/4 | 26.67 | 9.40 | 42.67 | SAPW | Stainless Steel 316 | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 | ||
| SAPW-12T-12P-S316 | 3/4 | 19.50 | 3/4 | 26.67 | 14.73 | 47.50 | SAPW | Stainless Steel 316 | Connectors Fractional Hy-Lok Port To Pipe | ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 |
