Female Connector

$0.00

  • Zero clearance.
  • Vacuum to high pressure.
  • Wide temperature range up to 550ºF.
  • Easy installation and maintenance.
  • Safety leak test ports.
  • Converts male NPT thread to ZCO gland.

Tube Fittings DIN2353

Category:

Description

Product Connection Type Dimension d (mm) Dimension d (in) Dimension L (in) Dimension L (mm) Hex Flat H (in) Size (in) Size P (in) Working Pressure (psig) Working Pressure (bar) PDF
H-ZCOFC4-2N-S316 Female NPT 4.57 0.180 1.250 31.75 5/8 1/4 1/8 8400 570 PDF
H-ZCOFC4-4N-S316 Female NPT 4.57 0.180 1.390 35.31 3/4 1/4 1/4 6600 450 PDF
H-ZCOFC8-6N-S316 Female NPT 10.16 0.400 1.570 39.88 15/16 1/2 3/8 6600 450 PDF
H-ZCOFC8-8N-S316 Female NPT 10.16 0.400 1.770 44.96 1 1/16 1/2 1/2 4900 330 PDF
H-ZCOFC12-12N-S316 Female NPT 15.75 0.620 1.930 49.02 1 5/16 3/4 3/4 4600 310 PDF
H-ZCOFC16-16N-S316 Female NPT 22.10 0.870 2.020 51.31 1 5/8 1 1 4400 300 PDF
