| Product | Body Flat (F) (in) | Dimension C (in) | Dimension C (mm) | Dimension L (in) | Dimension L (mm) | Tube O.D. (in) | Tube O.D. (mm) | Wall Thickness (in) | Wall Thickness (mm) | Working Pressure (psig) | Working Pressure (bar) | |
| H-MX-4 | 7/16 | 0.75 | 19.05 | 1.230 | 31.20 | 1/4 | 0.035 | 5100 | 351 | |||
| H-MX-6 | 7/16 | 0.75 | 19.05 | 1.200 | 30.50 | 3/8 | 0.035 | 3300 | 227 | |||
| H-MX-8 | 11/16 | 0.75 | 19.05 | 1.340 | 34.00 | 1/2 | 0.049 | 3700 | 254 | |||
| H-MX-6M | 7/16 | 0.75 | 19.05 | 1.230 | 31.20 | 6 | 1.0 | 6095 | 420 | |||
| H-MX-8M | 7/16 | 0.75 | 19.05 | 1.230 | 31.20 | 8 | 1.0 | 4499 | 310 | |||
| H-MX-10M | 5/8 | 0.75 | 19.05 | 1.340 | 34.00 | 10 | 1.0 | 3483 | 240 | |||
| H-MX-12M | 5/8 | 0.75 | 19.05 | 1.340 | 34.00 | 12 | 1.0 | 2902 | 200 |
