Product | Inlet End Connection | Dimension L (mm) | Dimension A (mm) | Dimension L (in) | Dimension A (in) | |
PVF-2N-BRAS | 1/8 Female NPT | 39.60 | 13.5 | 1.560 | 0.530 | |
PVF-4N-BRAS | 1/4 Female NPT | 44.40 | 18.3 | 1.750 | 0.720 | |
PVF-6N-BRAS | 3/8 Female NPT | 46.00 | 19.8 | 1.810 | 0.780 | |
PVF-8N-BRAS | 1/2 Female NPT | 50.30 | 24.6 | 1.980 | 0.970 | |
PVM-2N-BRAS | 1/8 Male NPT | 41.10 | 9.7 | 1.620 | 0.380 | |
PVM-4N-BRAS | 1/4 Male NPT | 46.00 | 14.2 | 1.810 | 0.560 | |
PVM-6N-BRAS | 3/8 Male NPT | 46.70 | 14.2 | 1.840 | 0.560 | |
PVM-8N-BRAS | 1/2 Male NPT | 53.10 | 19.1 | 2.090 | 0.750 | |
PVM-4U-BRAS | 1/4in., 7/16-20 | 42.90 | 9.7 | 1.690 | 0.380 | |
PVM-8U-BRAS | 1/2in., 3/4-16 | 46.00 | 11.2 | 1.810 | 0.440 | |
PVH-2T-BRAS | 1/8 Hy-Lok | 46.70 | 15.24 | 1.840 | 0.590 | |
PVH-4T-BRAS | 1/4 Hy-Lok | 49.30 | 17.78 | 1.940 | 0.690 | |
PVH-6T-BRAS | 3/8 Hy-Lok | 51.60 | 19.3 | 2.030 | 0.750 | |
PVH-8T-BRAS | 1/2 Hy-Lok | 55.60 | 21.84 | 2.190 | 0.880 | |
PVH-6M-BRAS | 6mm Hy-Lok | 49.30 | 17.7 | 1.940 | 0.690 | |
PVH-8M-BRAS | 8mm Hy-Lok | 50.80 | 18.6 | 2.000 | 0.720 | |
PVT-4T-BRAS | 1/4 Tube Stub | 47.50 | 16.0 | 1.870 | 0.630 | |
PVT-6T-BRAS | 3/8 Tube Stub | 49.30 | 17.5 | 1.940 | 0.690 | |
PVT-8T-BRAS | 1/2 Tube Stub | 54.60 | 23.1 | 2.150 | 0.910 | |
PVF-2N-S316 | 1/8 Female NPT | 39.60 | 13.5 | 1.560 | 0.530 | |
PVF-4N-S316 | 1/4 Female NPT | 44.40 | 18.3 | 1.750 | 0.720 | |
PVF-6N-S316 | 3/8 Female NPT | 46.00 | 19.8 | 1.810 | 0.780 | |
PVF-8N-S316 | 1/2 Female NPT | 50.30 | 24.6 | 1.980 | 0.970 | |
PVM-2N-S316 | 1/8 Male NPT | 41.10 | 9.7 | 1.620 | 0.380 | |
PVM-4N-S316 | 1/4 Male NPT | 46.00 | 14.2 | 1.810 | 0.560 | |
PVM-6N-S316 | 3/8 Male NPT | 46.70 | 14.2 | 1.840 | 0.560 | |
PVM-8N-S316 | 1/2 Male NPT | 53.10 | 19.1 | 2.090 | 0.750 | |
PVM-4U-S316 | 1/4in., 7/16-20 | 42.90 | 9.7 | 1.690 | 0.380 | |
PVM-8U-S316 | 1/2in., 3/4-16 | 46.00 | 11.2 | 1.810 | 0.440 | |
PVH-2T-S316 | 1/8 Hy-Lok | 46.70 | 15.24 | 1.840 | 0.590 |
