Hex Coupling

  • Precision pipe fittings for instrumentation and process control
  • Fine threads constructed to ensure leak-free & reliable systems
  • Male threads are protected with plastic cap
  • Various materials including SS316, Brass and Carbon steel
  • Many choice of connections and configurations are available
  • Female NPT both ends
Contact us
Find a distributor
Category

Description

Product Dimension A (mm) Dimension E (mm) Dimension H (Hex) (mm) Pipe Size (in) PDF
H-SSA-2N-BRAS 20.3 8.90 14.20 1/8 PDF
H-SSA-4N-BRAS 30.0 11.70 19.05 1/4 PDF
H-SSA-6N-BRAS 33.0 15.00 22.20 3/8 PDF
H-SSA-8N-BRAS 39.4 18.70 26.90 1/2 PDF
H-SSA-12N-BRAS 41.0 23.50 31.80 3/4 PDF
H-SSA-16N-BRAS 50.5 29.70 41.20 1 PDF
H-SSA-2N-STEL 20.3 8.90 14.20 1/8 PDF
H-SSA-4N-STEL 30.0 11.70 19.05 1/4 PDF
H-SSA-6N-STEL 33.0 15.00 22.20 3/8 PDF
H-SSA-8N-STEL 39.4 18.70 26.90 1/2 PDF
H-SSA-12N-STEL 41.0 23.50 31.80 3/4 PDF
H-SSA-16N-STEL 50.5 29.70 41.20 1 PDF
H-SSA-2N-S316 20.3 8.90 14.20 1/8 PDF
H-SSA-4N-S316 30.0 11.70 19.05 1/4 PDF
H-SSA-6N-S316 33.0 15.00 22.20 3/8 PDF
H-SSA-8N-S316 39.4 18.70 26.90 1/2 PDF
H-SSA-12N-S316 41.0 23.50 31.80 3/4 PDF
H-SSA-16N-S316 50.5 29.70 41.20 1 PDF
